The curved surface laminating machine is controlled by the programmable controller program, with reliable action and simple operation. The platform can be adjusted up and down on the X-axis, Y-axis, and theta angle to adapt to various alignment conditions, ensure bonding accuracy, and has the ability to self-dissipate static electricity to prevent electrostatic dust pollution. This article uses APDL language to carry out the specific process of parametric finite element analysis of the Vacuum curved surface bonding machine's rotating body, that is, the script process of software development.

The geometric structure simplification and gravity compensation, grid accuracy processing and division, constraint application, load calculation and application methods are elaborated in detail. The APDL command stream of the cylindrical parametric finite element analysis is encapsulated in VB language, and the parametric finite element analysis software of the rotating body of the large curved surface laminating machine is obtained.

The software is used to analyze the strength and rigidity of a series of large-scale curved surface laminating machines under full load, static and normal conditions, and the corresponding stress and deformation results of the revolving body are obtained. The result shows that the given design scheme is reasonable. This also verifies the practicability and reliability of this soft state.

Using the software developed in this paper, through variable parameter input, a mesh model of the same series of rotating bodies (similar in structure but different in size) can be obtained, and a series of processes such as parametric application, solution and post-processing of constraints and loads can be automatically completed. Provide the stress distribution and structural deformation of a given rotating body design plan.

In this way, for the same series of products, only by changing the corresponding parameter size, the finite element analysis results can be obtained automatically and quickly, saving a lot of repetitive processes, greatly improving the analysis efficiency, and providing a rapid improvement to the given design plan. Based on this, shorten the design cycle, reduce design and trial production costs, quickly launch qualified new products, and occupy the market.
